Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance

  • 1
  • 2

Brand Name : Realpark

Model Number : RP-ENTRY-TS01

Certification : CE and ISO9001

Place of Origin : Guangdong, China

MOQ : 10 sets

Price : Welcome to contact us!

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 1000 set/Month

Delivery Time : 4-6 weeks

Packaging Details : 52*42*152cm/45kgs/Wooden

Type : Parking Lot Machine, Entryof Parking Lot

Gross Weight : 45kgs

Carton Package : 52*42*152cm

Customization : Color/Logo/OEM/ODM

Compatibility : Integrated Parking Security Systems

Modular : Easy to maintain construction

Class Of Protection : IP54

Carton Packing Weight : 45kgs

Ticket Support : Thermal Ticket printer

Color Support : Customised

Classic Color : White/Black/Customised

Connectivity : Internet, RS485

Receipt Printing : Yes

Lcd Size : 10.1-inch

Ticket Printing : Yes

Contact Now

Parking Lot Kiosk With NFC Card &Ticket Printer for Entry Ticket Parking Machine


The RP-Entry-TS01 is a high-efficiency parking entry kiosk designed for seamless access control and ticket management. Equipped with NFC card recognition and a built-in ticket printer, it ensures smooth entry for both registered users (via NFC) and visitors (via printed tickets). Ideal for parking lots, garages, toll stations, and gated communities, this rugged kiosk enhances security while reducing manual operations.

Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance

Parking Lot Kiosk​ Key Features

✔ NFC Card Reader – Supports contactless access for authorized vehicles.
✔ High-Speed Ticket Printer – Issues instant entry tickets with time/date stamp.
✔ Durable Metal Housing – Weatherproof (IP65) for indoor/outdoor use.
✔ User-Friendly Touchscreen (Optional) – Intuitive interface for easy operation.
✔ Real-Time Data Sync – Integrates with parking management software.
✔ LED Indicators & Voice Prompts – Guides users through entry process.
✔ Wide Compatibility – Works with barriers, payment systems, and cloud platforms.

Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance
Entry Ticket Parking Machine Benefits:

✅ Reduces Queues – Fast NFC/ticket entry minimizes wait times.
✅ 24/7 Automation – No need for on-site staff.
✅ Prevents Fraud – Unique ticket codes + NFC authentication.
✅ Easy Integration – Connects to barriers, payment terminals, and LPR systems.
✅ Low Maintenance – Built for heavy-duty, long-term use.

Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance

Automatic Car Parking Ticket Kiosk Applications:

Shopping Malls & Commercial Parking
Airports & Train Stations
Office Buildings & Gated Communities
Temporary Event Parking
Municipal & Smart City Projects

Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance

Parking Entry Payment Ticket Kiosk Specification
Core Parameters CPU: 4 Core, 1.8G, Cortex-A55
Memory: Memory 2-8GB,
Interface Support TF, Optional, Max: 128G
Supports 6 USB HOST, 1 USB OTG2 serial port for USB camera, and supports TTL optional RS232 serial port. 1 set of RS485. Supports external serial device modules (3G module, NFC module, printer, card reader, etc.) 1 set of I2C port //*TF card, supports up to 128GBD class extra large built-in speaker, 5W/8Ω *2 supports microphone
General Parameters Power supply: input: AC100-240V, 50-60HZ, out put: DC12V 4A
Operating temperature range: -20℃ to +60℃.
1.5 mm steel housing (Anti-corrosion treated)
Easy Access to internal components through front door equipped with a security lock.
All components easily accessible.
Customized side/front panel color
Customized housing and side/front panel colors.
Internal Components 10.1-inch Color LCD screen
Thermal printer for the printing of parking tickets.
QR code scanner for the reading of all types of parking tickets.
Android control board.
Thermostatically controlled cooling system with fan.

Power supply with isolation switch.

Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance
Parking Ticket Payment Dispenser FAQS:
Q1: What payment processors are supported?
A: Compatible with Visa, Mastercard, UnionPay, Alipay, WeChat Pay, and major NFC wallets.

Q2: Can it print parking validation tickets?
A: Yes, the thermal printer supports both parking tickets and payment receipts.

Q3: What's the recognition speed for QR codes?
A: Less than 1 second with our high-performance scanner.

Q4: Is the POS terminal PCI compliant?
A: Yes, meets PCI PTS 5.x security standards.

Q5: How does it handle power outages?
A: Built-in UPS provides 2+ hours backup power.

Q6: Can it integrate with existing barrier gates?
A: Yes, supports RS485, TCP/IP, and Wiegand protocols.

Q7: What's the operating temperature range?
A: -30°C to 60°C (-22°F to 140°F) operation.

Q8: How are software updates handled?
A: Remote OTA updates with version rollback capability.

Q9: What maintenance is required?
A: Only thermal paper replacement; designed for 100,000+ transactions.

Q10: Do you provide transaction analytics?
A: Yes, our cloud dashboard shows payments by method, time, and location.
Modular Parking Lot Kiosk with Thermal Ticket Printer Easy Entry Ticket Support and Maintenance
